DAYAO PRODUCT
DRS37 SERIES
DRS37系列
Product specifications
1. Switch Rating : 0.1A 125VAC
2. Leakage : 500 megaohms min. between contacts to ground
3. Operating Temperature : 105C (221°F)
4. Leads :
Insulated appliance wire 20 AWG. stranded 150c .032"(0.81mm) thick insulation
UL NO. 3321.
5. 100% electrical continuity test required on each harness.
6. Switch to turn freely without noticeable noise.
7. Applications Product : Stove
