DAYAO PRODUCT
DSD-001 SERIES
DSD-001系列
Product specifications
1. Contact Rating : 0.5A, 125V AC
0.5A, 20V DC
2. Initial Contact Resistance : 30mQ Max
3. Insulation Resistance : 500MQ (MIN) 500 VDC
4. Life cycles : 50,000 cycles
5. Terminal to Terminal Dielectric Withstand Voltage : 200 VAC-1 minute
6. Applications Product : Weeding Machine, Polisher, Ironing Machine, Mouse
