DAYAO PRODUCT
DSD013 SERIES
DSD013系列
Product specifications
Specifications
1. Rating : 4.5A 12VDC (LAMP)
2. Voltage Drop : 0.2V at rating load
3. Insulating Impedance : 10Mohm MIN by 500V
4. Endurance : 100,000 cycles at rating load
5. Operating Force : 400 ± 300gf
6. Applications Product : Locomotive Brake Lights
