DAYAO PRODUCT
DTG18 SERIES
DTG18系列
Product specifications
1. Contact Rating : 20.5A,24VDC (UL& C-UL)
2. Initial Contact Resistance : 30m2(MAX.)
3. Insulation Resistance : 100M(MIN) 500 VDC
4. Operation Force : 20±3 N
5. Life cycles : More than 100,000 cycles
6. Terminal to Terminal Dielectric Withstand Voltage : 500 VAC-1 minute
7. Applications Product : Drill, Chain Saw, Hammer Drill
