DAYAO PRODUCT
DTG21 SERIES
DTG21系列
Product specifications
1. Contact Rating : 21A, 42VDC
2. Initial Contact Resistance : 5mQ
3. Insulation Resistance : 500MQ
4. Life cycles : 100,000 cycles
5. Terminal to Terminal Dielectric Withstand Voltage : 500VAC-1 minute
6. Terminal to Enclosure Dielectric Withstand Voltage : 500VAC-1 minute
7. Applications Product : Drill, Chain Saw, Hammer Drill
